Q-Switched Nd:YAG Laser · Tattoo Removal; Pigmentation Removal
The QM-Q1 tattoo removal machine is a laser machine developed by our factory. Precision, safety, and efficiency, this device Q-switched Nd:YAG laser technology to remove unwanted tattoos, pigmented lesions, and improve overall skin tone. With its modern design, user-friendly interface, and multiple treatment modes, the QM-Q1 is one of the appropriate tattoo removal machines for clinics and aesthetic centers.
Q-Switched Nd:YAG laser technology is widely used in aesthetic and dermatological treatments due to its high energy output and photoacoustic effects. It offers intended for trained professional operation solutions for a variety of skin concerns, including:
Efficiently removes unwanted tattoos across a range of colors.
1064nm wavelength: Ideal for dark inks such as black, blue, and green
532nm wavelength: Targets brighter inks like red, orange, and yellow
This technology breaks down ink particles into fine fragments that are naturally eliminated by the body, with minimal risk of scarring.
Effectively treats a wide range of benign pigmentation issues, such as:
1320nm wavelength Low-energy settings can stimulate collagen regeneration and improve skin tone by reducing dullness and refining pores—commonly known as “laser toning” or “carbon facial” when combined with carbon paste.
Dual wavelengths, Q-Switched Nd:YAG lasers can precisely target both superficial and deep pigment deposits, supporting effective results for multi-layer skin concerns.
With its selective targeting and minimal downtime, Q-Switched Nd:YAG laser is configurable for Fitzpatrick skin types I–VI, making it a popular choice for clinics treating diverse patient populations.
Working Principle – How It WorksThe nanosecond high-intensity pulses generated by the Q-switched Nd:YAG laser decompose pigment particles while managing exposure to the surrounding skin based on the principle of photodisruption which is mainly a mechanical effect.
1064nm wavelength——Ideal for black, blue, and deep tattoos. It penetrates deeply into the skin to fragment dark pigments.
532nm wavelength——Effective for red, orange, and lighter colors. It precisely shatters superficial pigments.
1320nm wavelength——Commonly used for carbon peeling, skin rejuvenation, and shrinking enlarged pores, ect.
755nm wavelength——used for epidermal & dermal pigments, melasma, freckles, skin brightening
Once pigment particles absorb the energy, they break into smaller fragments. The body’s natural metabolism then removes these fragments over time, resulting in fading or complete clearance of the tattoo.
Ergonomic HandpieceThe handle is designed with full consideration of ergonomics. It is light in weight, comfortable to hold, and easy to operate, effectively reducing operator fatigue and providing a more humane treatment experience.
Multi-Wavelength TechnologyFour wavelengths (1064nm, 532nm, 1320nm and 755nm optional) allow versatile applications, from tattoo removal to carbon peeling and skin rejuvenation.
Four Colors AvailableThe machine is available in four different color options, so clinics can choose the style that appropriate suits their environment or branding.
Adjustable & Rotating TouchscreenThe screen can be flipped and rotated to multiple angles, making it convenient for operators to adjust settings easily, regardless of treatment position.
Friendly User InterfaceThe intelligent touchscreen interface provides pre-set parameters for beginners and customizable modes for professionals.
Large tattoo removal
Small tattoo removal
Eyebrow Tattoo Removal
Technical Specifications| Peak Power | 500W |
| Wavelength (Spectrum) | 1064nm, 532nm, 1320nm (755nm optional) |
| Energy Density (Fluence) | 10-2000mJ |
| Spot Size | 2-7mm |
| Pulse Repetition Rate | 1-10Hz |
| Pulse Duration | <7ns |
| YAG Bar Size | ¢7 |
| Cooling | Air cooling Closed water circulation cooling |
| Stand-by Working | Continuously for 15 hours |
| Display | 10.4"True Color LCD Touch Screen |
| Electrical Requirements | 110/230VAC, 15/20A max., 50/60Hz |
| Gross Weight | 28kgs |
| Dimensions (WxDxH) | 57*42*54cm |
Most people describe the feeling as a quick snapping sensation. Thanks to the built-in cooling system, discomfort is usually mild, and many clients say the procedure is easier than expected.
It depends on tattoo size, color, and depth. On average, 4-6 sessions are needed, but some tattoos show noticeable fading after just 2–3 treatments.
Black, blue, and dark pigments respond the fastest. Red and orange also fade well. Lighter colors like yellow and green are harder, but the QM-Q1 still achieves visible improvement over time.
Scars are extremely rare. The QM-Q1 uses precise energy delivery, reducing the chance of skin damage. With proper aftercare, the skin usually heals smoothly.
Keep the treated area clean, avoid sun exposure, and apply soothing ointment if needed. Redness or swelling typically subsides within a few days, allowing clients to return to normal life quickly.
Choosing the right tattoo removal machine is not only about advanced technology but also about long-term support. At our factory, we don’t just sell machines—we build lasting partnerships with our clients.
Free Accessory Replacement:Except for consumables like knife heads, any other accessories damaged during use can be replaced free of charge. You only need to cover the shipping cost.
One-on-One Training:Upon delivery, our professional engineers provide personalized training, guiding you step by step on how to operate the machine with confidence.
Customized Solutions (OEM/ODM)– We offer full OEM/ODM services to provide tailored solutions that meet your brand identity and diverse business needs, supporting your machine is truly unique.
Commitment to Responsibility:We take full responsibility for every machine we sell, supporting that our clients always receive the appropriate performance and support.
With our factory team, you’re not only investing in the appropriate tattoo removal machine, but also in a trusted partner dedicated to your success.
